Correctable Error
2. When selecting O.182 Poisson:
a. Insertion ModeInsertion Mode is fixed to RateRate.
Touch the RateRate field to set the error insertion rate.
b. Select the Exclude FASExclude FAS.
Selecting OnOn inserts errors at any position excluding FAS when the
rate is 2.0E-3 or larger. This settings avoids the occurrence of LOF by
inserting errors into FAS.
3. When selecting Uncorrectable Error or Correctable Error:
a. Touch the Sub-rowSub-row field to set the sub-row.
b. Insertion ModeInsertion Mode is fixed to SingleSingle.
Touch the Error InsertError Insert icon. The error is inserted once by touching the
icon.
For O.182 Poisson, refer to the white paper on Anritsu homepage:
FEC Efficiency New Test Method - Required by ITU-T New Rec. O.182 -
OTLOTL
1. Select the TypeType.
2. Select the Alarm ItemAlarm Item or Error ItemError Item.
3. Select the Insertion ModeInsertion Mode. When setting to BurstBurst, touch BurstBurst field and set
value. When setting to AlternateAlternate, touch Error lengthError length, Normal lengthNormal length fields and
set values.
4. Touch the buttons of LaneLane, the dialog box will appear.
5. Touch the buttons to select/clear lanes. The errors will be inserted to selected
(orange) lanes.
77..11..44..22 OTN OTL skewOTN OTL skew
1. Touch the field below the port selection to set the number of skew bits. The
calculated skew time is shown below the field.
2. When the output signal is set to OTU4, select the Lane typeLane type.
3. Touch the buttons of Insertion LanesInsertion Lanes, the dialog box will appear.
4. Touch the buttons to select/clear lanes. The skew will be inserted between
selected (orange) lanes and non selected (gray) lanes.
Setting to "0" means that inserting no skew.
77..11..44..33 OTN frequencyOTN frequency
Touch the field to set Frequency OffsetFrequency Offset. If setting a positive value, the frequency
will shift higher side.
Example:
If setting 100 ppm to the frequency offset for OTU2 output signal, the bit rate
of output signal will be
10 709 225.316 * (1+100*10
-6
) = 10 710 296.239 (kbit/s).
Nominal bit rates defined in ITU-T are shown below.
OTN Setup and StatusOTN Setup and Status
469469
