This screen presents information about the current state of the link.
RxRx
Signal levelSignal level: shows the optical signal level in dBm. If the optical signal
detection failed, a red indicator appears on the right.
Bit rateBit rate: shows the actual bit rate of the receiver (in bps).
DeviationDeviation: shows the deviation from the relevant nominal bit rate.
Pattern bit ratePattern bit rate: shows the bit rate of the pattern in received frames (in bps).
TxTx
Signal levelSignal level: shows the output power of the optical transmitter.
Bit rateBit rate: shows the actual bit rate of the transmitter (in bps)
DeviationDeviation: shows the deviation from the relevant nominal bit rate.
Pattern bit ratePattern bit rate: shows bit rate of the pattern in transmitted frames (in bps).
88..11..33..33 Alarms and ErrorsAlarms and Errors
Touching the middle summary box in the status area of the Ports SetupPorts Setup screen
displays the status shown below.
