Pattern errorPattern error : Bit error of the pattern
FEC Alarms/ErrorsFEC Alarms/Errors
These indicators appear if FEC enableFEC enable is selected.
LOFALOFA: Loss of frame alignment
Corr. CWCorr. CW: Corrected Codewords
Uncorr. CWUncorr. CW: Uncorrected Codewords
FEC symbol errorsFEC symbol errors: Symbol error(s)
RemoteRemote
Lights in red when the receiving bit in L1 Inband Protocol is "1". These bits are
located in Z.130.0 in the hyperframe.
Remote LOSRemote LOS: Loss of Signal detection
Remote LOFRemote LOF: Loss of Frame detection
RAIRAI: Remote Alarm Indication
SDISDI: SAP (Service access point) Defect Indication
ResetReset: Master - Reset acknowledge, Slave - Reset request
LinkLink
CPRICPRI OBSAIOBSAI
Shows the CPRI Link status.
Link state and Port role appear when
Start up is set to EnabledEnabled.
Rx
Protocol version
HDLC rate
Pointer
Tx
Protocol version
HDLC rate
Pointer
Displays status defined by OBSAI RP3.
Tx State
TX_OFF
IDLE
*1
IDLE_REQ
*2
IDLE_ACK
*2
FRAME_TX
Rx State
UNSYNC
WAIT_FOR_SEED
*2
WAIT_FOR_ACK
*2
WAIT_FOR_K28.7_IDLES
WAIT_FOR_FRAME_SYNC
FRAME_SYNC
*1: When Line Rate is set to other than
6144.0 Mbps6144.0 Mbps
*2: When Line Rate is set to 6144.0 Mbps6144.0 Mbps
88..11..33..44 TransceiverTransceiver
Refer to Transceiver in "Ethernet Setup and Status".
