1111..11..22 Running the ScenarioRunning the Scenario
When scenario is loaded, the icon appears in Scenario of the Utilities screen. If
touching the icon, the following screen is displayed.
This screen displays the Pass/Fail results and status of the scenario execution.
Select the check box for the application name you want to run.
To run the scenario, touch in the Application Toolbar.
Results folderResults folder
The destination folder to save the result file is displayed. Touch the field to
open the dialog box and select the folder. If selecting AutoAuto, the folder name will
be generated automatically.
The button to specify the destination drive appears when touching an icon on
the Utilities screen after USB flash drive was connected to the Network Master.
Even if Result folder :UsbResult folder :Usb has been set, result files are stored in Internal
memory temporary and moved to USB flash drive after the scenario execution
has finished.
In cases below, a warning message appears when Network Master attempts to
save result files to USB flash drive. If Network Master failed to save result files
to USB flash drive, they are stored in Internal memory.
The USB flash drive was removed.
The free space of the USB flash drive is insufficient.
Application and the result displayApplication and the result display
In the upper table, Application name, Port number for test use, and comment
which are written in the scenario are displayed. If the scenario has executed,
the test result and the result file name appear in the each column.
Status indication during Scenario executionStatus indication during Scenario execution
In the lower table, the status of the application and the time that has occurred
are displayed.
