OH CaptureOH Capture
TransceiverTransceiver
Through ModeThrough Mode
APSAPS
Delay measurementDelay measurement
Item
TOH: 64 Frames
POH: 64 Frames
Pathtrace:J0/J1/J2 (Displays in ASCII characters)
Timing
Single
Repeat : Update period 1s
Module Present
Transceiver Information
Alarm, Wavelength and bit rate, Compliance, Vendor Information, Output
Control
Power monitor
I2C analysis
For SFP and SFP+:
Memory A0h, Memory A2h, Read/Write
Mode :
Through
OH Overwrite
TOH, A1/A2, K1/K2, S1, DCC1-3, DCC4-12, J0, TOH 1byte
Stimuli
Alarm : LOS, LOF, OOF, RDI-L
Available alarms depend on Through mode setting.
Error : A1A2, B1, B2, REI-L, ERR-TRANS
Available errors depend on Through mode setting.
Insertion: refer to Alarm Insertion and Error Insertion.
APS (Automatic Protection Switching) Measurement
Reference event : LOS, LOF, OOF, AIS-L, RDI-L, APS Switchover, AIS-P, LOP-P,
TIM-P, PLM-P, UNEQ-P, LOM-V, AIS-V, LOP-V, TIM-V, PLM-V, UNEQ-V, LSS,
A1A2, B1, B2, REI-L, B3, V5, Patter errors
Max reference duration: 0.000 to 10000.000 ms
Result : Average switching time, Maximum switching time, Minimum
switching time
APS Protocol analyze
APS configuration :Ring or Linear
Ring : Short Path, Long Path
Linear : 1+1 architecture, 1:n architecture
APS Protocol Request : The value of K1, K2 byte is sent depending on selected
type.
APS Interpretation : Number, Elapsed Time
Measurement Mode : Single, Repeat
Measurement Period : 0.5, 1, 2, 5, 10 s
Measurement Range : Up to 10 000 000.000 μs / resolution 0.1 μs, Timeout
