SONET PerformanceSONET Performance
MeasurementMeasurement
Tributary ScanTributary Scan
Number of portsNumber of ports
Frame formatFrame format
Frequency OffsetFrequency Offset
BER Test patternsBER Test patterns
Line build outLine build out
Setup : G826, G.828+G.829, M.2101.1(M2100)
Allocation
Mux Allocation 0 to 100%
STS-3c Allocation 0 to 100%
STS-1 Allocation 0 to 100%
VT-2/VT-1.5/VC-12 Allocation 0 to 100%
Time period : 15minutes, 1hour, 2hour, 24hour, 7days (only M.2101.1)
Result : ES, SES, BBE, UNAV
Display : Count, Ratio
Displays the alarm status of all channels in a specified layer.
Green (No alarm), Red (Alarm occurring), Gray (Not applied)
1212..55..22..33 PDHPDH
Max. 2
Non PCM frame
Bit rate : Refer to .
Framed
Bit rate (Format)
E1 2.048Mbit/s (30,31ch with or without CRC4, Sa-bit, CAS)
E3 34.368Mbit/s (G.751)
E4 139.264Mbit/s (G.751)
DS1 1.544Mbit/s (T1.107, SF/ESF/Japan ESF, CAS)
DS3 44.736Mbit/s (T1.107, M13/C-bit)
Mux/DeMux
E1 n*64kbit/s
DS1 n*64kbit/s or n*56kbit/s
±125 ppm 1 ppm step
PRBS:
E1
2
6
−1, 2
7
−1, 2
9
−1, 2
11
−1, 2
15
−1, 2
20
−1, 2
23
−1, QRSS 11, QRSS 20
E3/E4
2
9
−1, 2
11
−1, 2
15
−1, 2
20
−1, 2
23
−1, 2
29
−1, 2
31
−1, QRSS 20
(2
29
−1, 2
31
−1 and QRSS 20 are only available for E4.)
DS1/DS3
2
9
−1, 2
11
−1, 2
15
−1, 2
20
−1, 2
23
−1, 2
29
−1, 2
31
−1, QRSS 20
Fixed : User Pattern (32bits, 2048bits), All0, All1, 1 in 1, 1 in 3, 1 in 7, 3 in 24,
Fox Pattern
(Fox Pattern is not available for E4.)
Logic : Normal, Inverse
DS1
0 dB, −7.5 dB, −15 dB, −22.5 dB, 1-133 ft, 133-266 ft, 266-399 ft, 399-533 ft, 533-
655 ft
SpecificationsSpecifications
