BER TestBER Test
CPRI Pass ThroughCPRI Pass Through
Interface TypeInterface Type
Bit RateBit Rate
Lane SelectLane Select
Timing sourceTiming source
Test PatternTest Pattern
Frequency OffsetFrequency Offset
Error InsertionError Insertion
Alarm, Wavelength and bit rate, Compliance, Vendor Information, Output
Control
Power monitor
Alarms:
Unframed: Signal loss, LSS
CPRI Link: Signal loss, LOS, LOF, LSS, Remote LOS, Remote LOF, RAI, SDI,
Reset
OBSAI Link: Signal loss, LOF, No message, LSS
Errors:
Unframed: Pattern error
CPRI Link: LCV, SHV, K30.7, Pattern error
OBSAI Link: LCV, K30.7, Pattern error
Frames count:
CPRI Link: Rx hyper frames, Rx code words, Tx hyper frames, Tx code words
OBSAI Link: Rx Message Groups, Tx Message Groups
Delay
Delay, Average Delay, Min Delay, Max Delay, Measurement count
APS
Switching Time
Alarm:
Signal loss, LOS, LOF, LSS, Remote LOS, Remote LOF, RAI, SDI, Reset
Errors:
LCV, SHV, K30.7
Frames count:
Rx hyper frames, Rx code words, Tx hyper frames, Tx code words
1212..55..66 Device TestDevice Test
Off, SFP28, QSFP28, QSFP56, QSFP-DD, OSFP
Off, 25G Ethernet, 40G Ethernet, 100G Ethernet, 200G Ethernet, 400G
Ethernet, OTU3, OTU3e1, OTU3e2, OTU4
4 Lane, 4 Lane (PAM4), 8 Lane (Logical), 8 Lane (PAM4), 16 Lane (Logical), 20
Lane (Logical)
Internal clock
External clock
PRBS7, PRBS9, PRBS15, PRBS23, PRBS31, Square Wave
*
200G Ethernet 4 Lanes and 400G Ethernet 8 Lanes:
PRBS13Q, PRBS31Q, Square Wave
*
200G Ethernet 8 Lanes and 400G Ethernet 16 Lanes:
PRBS7, PRBS9, PRBS13, PRBS15, PRBS23, PRBS31
*: Square Wave is available only for Tx pattern.
±200 ppm 0.1 ppm step
Item
Bit Error, Symbol Error
*
SpecificationsSpecifications
