1-6 Secure Environment Workplace General Information
1-10 PN: 10580-00318 Rev. P S412E UG
Recommended Usage in a Secure Environment
Set the LMR Master to save files to an external USB flash drive:
1. Attach the external Flash drive and turn on the instrument.
2. Press the Shift button then the File (7) button.
3. Press the Save submenu key.
4. Press the Change Save Location submenu key, then select the USB flash drive with the
rotary knob, Up/Down arrow keys, or the touchscreen.
5. Press the Set Location submenu key.
The external USB flash drive is now the default location for saving files.
Note
Not all after-market USB flash drives are compatible with the LMR Master. Many
drives come with a second partition that contains proprietary firmware. This
partition must be removed. Only one partition is allowed. Refer to the individual
manufacturer for instructions on how to remove it. Some drives can be made to
work by reformatting them using the FAT32 format.
