5-3 System Menu System Operations
5-4 PN: 10580-00318 Rev. P S412E UG
5-3 System Menu
Key Sequence: Shift, System (8)
Status: Press this submenu key to display the current system status,
including the operating system and firmware versions, temperatures and
other details such as current battery information. Press Esc or Enter to
return to normal operation.
Self Test: Press this submenu key to initiate a series of diagnostic tests that
check the components of the instrument. A display lists the individual tests
with a pass or fail indication. Press Esc or Enter to return to normal
operation.
Application Self Test: Press this submenu key to initiate a series of
diagnostic tests related to the performance of the instrument for specific
applications. A display lists the individual tests with a pass or fail indication.
Press Esc or Enter to return to normal operation.
GPS: Opens the “GPS Menu” on page 9-3. This submenu key is displayed
only when the GPS (Option 31) is installed.
Calibrate Touch Screen: Press this submenu key to start the touch screen
calibration. Run the calibration procedure when the instrument is not
responding to your screen taps as expected.
Application Options: Press this submenu key to open a menu to select
application options. This varies depending upon the measurement
(application) mode. Refer to “Application Options Menu” on page 5-5.
System Options: Press this submenu key to open the “System Options
Menu” on page 5-11.
Figure 5-3. System Menu
Note
Calibrate Touch Screen Shortcut
Press Shift then 0 to open the Calibrate Touch Screen display. Press Enter to start
the calibration or Esc to cancel.
System
System
Options
Application
Options
GPS
Status
Self
Test
Application
Self
Test
Calibrate
Touch
Screen
