System Operations 5-4 Application Options Menu
S412E UG PN: 10580-00318 Rev. P 5-5
5-4 Application Options Menu
Key Sequence: Shift, System (8) > Application Options
The display of this menu varies based on the current measurement mode. In addition to the
following information, refer to the appropriate Measurement Guide listed in Appendix A.
VNA Mode
Units
mft:Press this submenu key to toggle the units setting to metric (meters,
or m) or to U.S. (feet, or ft). Press Enter to accept the changes, or press the
Esc key to return to normal operation without changing the setting.
Trace Label
On Off: Press this submenu key to toggle the trace labels On or Off.
Meas Gain Range: Press this submenu key to open the Mode Menu.
Select Auto or Fixed.
Auto: Press this submenu key to set the Measurement Gain Range
Mode to Auto. In this mode, the instrument adjusts the gain
automatically to provide the best overall system performance
(dynamic range and high level noise).
Fixed: Press this submenu key to set the Measurement Gain Range
Mode to Fixed. In this mode, the gain of the instrument is always set to
the low gain setting. For most applications, Auto mode is
recommended. For certain types of filter measurements (mostly in the
range less than 500 MHz), the instrument may toggle between low
gain and high gain modes as the signal level rises from the noise to
the pass band of the filter, resulting in extra ripple. Setting the Gain
Range to fixed may address that problem.
Meas Menu
Field VNA: Press this submenu key to toggle between Field (a simplified
subset of the standard VNA menu structure) and VNA (standard menu
structure.
Back: Press this submenu key to return to the “System Menu” on page 5-4.
Figure 5-4. Application Options Menu (VNA Mode)
Back
Options
Units
m ft
Trace Label
On Off
Meas Menu
Field VNA
Meas Gain Range
Auto
