3-4 Vector Network Analyzer Quick Start Guide
3-4 PN: 10580-00318 Rev. P S412E UG
Select the Measurement Type
Press the Measure main menu key and then the Measurement Type submenu key. Select a
measurement graph and press Enter.
Set the Frequency
1. Press the Freq/Dist main menu key.
2. Press the Start Freq submenu key and use the keypad, rotary knob, or the arrow keys to
enter the start frequency.
3. Press the Stop Freq submenu key and use the keypad, rotary knob, or the arrow keys to
enter the stop frequency.
Set the Scale
1. Press the Scale main menu key.
2. For Smith Charts, select the appropriate zoom level. The graph expands or compresses
around the central reference impedance of the Smith Chart
3. For other graphs, set the To p and Bottom of the scale or press Autoscale.
Turn On Markers
1. Press the Marker main menu key.
2. Press the Marker submenu key to open the Select Marker list box and select a marker by
scrolling with the rotary knob or the arrow keys, then press Enter. Unused markers are
labeled OFF. The number on the Marker submenu key indicates the active marker.
3. Use the rotary knob, arrow keys, or touch and drag to move the Marker. The frequency
of the active Marker is shown in the upper-left corner of the display screen.
Peak and Valley Search Markers
When making measurements, the Peak Search and Valley Search features can be used to
quickly place a Marker on a maximum or minimum point of a trace.
1. With an active marker, press the Peak Search or the Valley Search submenu key to find
the maximum or minimum value on the trace that is associated with the current
marker.
Note
The following Quick Start instructions apply to VNA Field Mode. For detailed
measurement instructions, refer to the Vector Network Analyzer Measurement
Guide P/N 10580-00289, listed in Appendix A.
