Ethernet Connectivity 6-3 Ethernet Configuration on the LMR Master
S412E UG PN: 10580-00318 Rev. P 6-5
Ethernet Menu
Key Sequence: Shift, System (8) > System Options > Ethernet Config
Type
Manual DHCP: Press this submenu key to select whether the address will
be entered manually, or will be supplied automatically by a network DHCP
server. If Manual is selected, then use the submenu keys or the Left/Right
arrow keys to select the field that is to be modified. Use the keypad, the
Up/Down arrow keys, or the rotary knob to enter the input. Press Enter to
accept the changes, or press the Esc key to return to normal operation
without changing anything.
Field
IP G-Way Sub: Press this submenu key to select the desired Internet
Protocol Property to be edited.
First Octet: Moves the cursor to the left most column of the selected IP
properties field.
Second Octet: Moves the cursor to the second column from the left of the
selected IP properties field.
Third Octet: Moves the cursor to the third column from the left of the
selected IP properties field.
Fourth Octet: Moves the cursor to the forth column from the left of the
selected IP properties field.
Figure 6-3. Ethernet Menu
Ethernet
Type
Manual DHCP
Field
IP G-Way Sub
First Octet
Second Octet
Third Octet
Fouth Octet
