A-2 MS2024B Test Record Test Records
A-2 PN: 10580-00303 Rev. D Model MS20xxB MM
A-2 MS2024B Test Record
VNA Frequency Accuracy
VNA Transmission Dynamic Range
_____ Refer to Attached Test Data Report
VNA Return Loss Measurements Accuracy
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-1. VNA Frequency Accuracy
VNA Output Frequency Specification Frequency Counter Reading
1GHz ±2.5kHz kHz
Table A-2. VNA Return Loss Measurement Accuracy
Return Loss Specification Measured Value
6dB 5.05dB <
x < 6.95 dB dB
20 dB 18.39 dB <
x < 21.61 dB dB
