Anritsu VNA Master MS2024B Maintenance Manual

Test Fixture Schematics B-4 T3536 Test Fixture Schematic
Model MS20xxB MM PN: 10580-00303 Rev. D B-3
B-4 T3536 Test Fixture Schematic
Figure B-3. T3536 Test Fixture Schematic
3-116-10-5
10, 5%, 1 W
250-108
1000 μf
63 V
3-116-10-5
10, 5%, 1 W
3-130-36-5
36, 5%, 10 W
3-130-36-5
36, 5%, 10 W
513-32
