General Information 1-6 Recommended Test Equipment
Model MS20xxB MM PN: 10580-00303 Rev. D 1-5
Spectrum Analyzer Test Equipment
Table 1-5. Test Equipment Recommended for Spectrum Analyzer Verification
Instrument Critical Specification
Recommended
Manufacturer/Model
Frequency Reference Frequency: 10 MHz Symmetricom RubiSource T&M
Synthesized Signal Generator Frequency: 0.1 Hz to 20 GHz,
Power Output: +16 dBm,
Step attenuator installed
Anritsu Model MG3692B or
MG3692C with Options 2A, 4,
and 22 (Quantity 2)
Power Meter Power Range: –70 to +20 dBm Anritsu Model ML2438A
Power Sensor Frequency: 100 kHz to 18 GHz
Power Range: –30 to +20 dB
Anritsu Model SC7400 (Quantity 2)
Power Sensor Frequency: 100 kHz to 18 GHz
Power Range: –67 to +20 dB
Anritsu Model MA2442D
Adapter Frequency: DC to 18 GHz
N(m)-N(m), 50 Ohm
Anritsu Model 34NN50A
Adapter Frequency: DC to 18 GHz
RK(m)-N(f), 50 Ohm
Anritsu Model 34RKNF50
RF Coaxial Cable Frequency: DC to 18 GHz
Impedance: 50 ohm
Connector: N(m)-N(m)
Anritsu Model 15NN50-1.5C
(Quantity 2)
Coaxial Cable Impedance: 50 ohm
Connector: BNC(m) to BNC(m)
Anritsu 2000-1627-R (Quantity 3)
50 Ohm Termination Frequency: DC to 18 GHz
Impedance: 50 ohm
Connector: N(m)
Anritsu Model 28N50-2
Power Splitter Frequency: DC to 18 GHz
Connector: N(f)
Aeroflex/Weinschel Model 1870A
Fixed Attenuator Frequency: DC to 18 GHz
2 dB Attenuation
Aeroflex/Weinschel Model 44-2
(Quantity 2)
Fixed Attenuator Frequency: DC to 18 GHz
6 dB Attenuation
Aeroflex/Weinschel Model 44-6
(Quantity 2)
Fixed Attenuator Frequency: DC to 18 GHz
10 dB Attenuation
Aeroflex/Weinschel Model 44-10
(Quantity 2)
Fixed Attenuator Frequency: DC to 18 GHz
20 dB Attenuation
Aeroflex/Weinschel Model 44-20
(Quantity 2)
Tee Adapter Frequency: 10 MHz
Impedance: 50 ohm
Connector: BNC(m) to BNC(f)/BNC(f)
Anritsu 3-2600-2 (Quantity 2)
