Test Records A-5 MS2035B Test Record
Model MS20xxB MM PN: 10580-00303 Rev. D A-19
Spectrum Analyzer Spurious Response (Second Harmonic Distortion)
Spectrum Analyzer Input Related Spurious (IRS) Signals
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-39. Spectrum Analyzer Spurious Response (Second Harmonic Distortion
Frequency Specification Measured Value 2nd Harmonic Level
50.1 MHz dBm
100.2 MHz ≤ –56 dBc dBm dBc
Table A-40. Spectrum Analyzer Input Related Spurious (IRS) Signals
Frequency Specification Measured Values Calculated IRS
2072.5 MHz dBm
1222.5 MHz to 2072 MHz ≤ –60 dBc dBm dBc
2073 MHz to 2922.5 MHz ≤ –60 dBc dBm dBc
1500 MHz dBm
1219 MHz to 1221 MHz ≤ –52 dBc dBm dBc
1689.5 MHz to
1691.5 MHz
≤ –52 dBc dBm dBc
2821 MHz to 2823 MHz ≤ –52 dBc dBm dBc
2421.5 MHz dBm
2505 MHz to 2507 MHz ≤ –39 dBc dBm dBc
To Next Page
