Anritsu VNA Master MS2024B Maintenance Manual

Test Records A-4 MS2034B Test Record
Model MS20xxB MM PN: 10580-00303 Rev. D A-11
Spectrum Analyzer Amplitude Accuracy (continued)
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-23. Spectrum Analyzer Amplitude Accuracy Across Frequency – 100 MHz
Test Power
dBm
Atten Level
dB
Specification
(for SN <1441001)
dB
Marker 1 Reading
dBm
Deviation
dB
–30 0 ±1.25 (±1.3)
–30 5 ±1.25 (±1.3)
–30 10 ±1.25 (±1.3)
–30 20 ±1.25 (±1.3)
–2 30 ±1.25 (±1.3)
–2 40 ±1.25 (±1.3)
–2 50 ±1.25 (±1.3)
–2 55 ±1.25 (±1.3)
Table A-24. Spectrum Analyzer Amplitude Accuracy Across Frequency – 500 MHz
Test Power
dBm
Atten Level
dB
Specification
(for SN <1441001)
dB
Marker 1 Reading
dBm
Deviation
dB
–30 0 ±1.25 (±1.3)
–30 5 ±1.25 (±1.3)
–30 10 ±1.25 (±1.3)
–30 20 ±1.25 (±1.3)
–2 30 ±1.25 (±1.3)
–2 40 ±1.25 (±1.3)
–2 50 ±1.25 (±1.3)
–2 55 ±1.25 (±1.3)
