Anritsu VNA Master MS2024B Maintenance Manual

Removal and Replacement 6-10 Ethernet PCB Assembly (Option 411) Replacement
Model MS20xxB MM PN: 10580-00303 Rev. D 6-27
Ethernet PCB Assembly
1. Screw (4 total) to attach Option 411 PCB to Main/VNA PCB Assembly
2. Connector J1 (Mother Board to SPA PCB ribbon cable connector)
3. VNA shield
4. Ethernet LAN Connector
5. GPS PCB on Mother Board
Figure 6-19. Option 411 (Ethernet LAN) PCB Attached to Mother Board
1
5
4
2
1
1
3
