A-5 MS2035B Test Record Test Records
A-16 PN: 10580-00303 Rev. D Model MS20xxB MM
Spectrum Analyzer Residual Spurious Response
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-32. Spectrum Analyzer Residual Spurious Response with Preamp Off
Start Freq Stop Freq RBW VBW Specification Measured Values
10MHz 50MHz 1kHz 300Hz ≤ –90 dBm dBm
50 MHz 2.0 GHz 3 kHz 10 kHz ≤ –90 dBm dBm
2.0GHz 4.0GHz 1kHz 1kHz ≤ –90 dBm dBm
4.0GHz 5.0GHz 1kHz 3kHz ≤ –90 dBm dBm
5.0GHz 5.2GHz 1kHz 1kHz ≤ –90 dBm dBm
5.2GHz 5.7GHz 300Hz 3kHz ≤ –90 dBm dBm
5.7GHz 5.9GHz 300Hz 3kHz ≤ –90 dBm dBm
5.9GHz 6.0GHz 1kHz 100Hz ≤ –90 dBm dBm
Table A-33. Spectrum Analyzer Residual Spurious Response with Preamp On
Start Freq Stop Freq RBW VBW Specification Measured Values
10 MHz 1.0 GHz 1 kHz 300 Hz ≤ –90 dBm dBm
1.0GHz 4.0GHz 3kHz 10kHz ≤ –90 dBm dBm
4.0 GHz 6.0 GHz 30 kHz 3 kHz ≤ –90 dBm dBm
