Anritsu VNA Master MS2024B Maintenance Manual

Removal and Replacement 6-2 Internal Anatomy of All Four VNA Master Models
Model MS20xxB MM PN: 10580-00303 Rev. D 6-5
Basic Case Parts
The Case Front includes the Keypad, Touch Screen, LCD, and Fan.
The Case Back includes the Battery Compartment and its Door.
Figure 6-3 also shows the Tilt Bail and the 3 vents (ventilation grills) for Fan intake and exhaust.
Figure 6-3. Perspective View of Case Parts (Case bottom is Facing Upward)
