Anritsu VNA Master MS2024B Maintenance Manual

A-4 MS2034B Test Record Test Records
A-8 PN: 10580-00303 Rev. D Model MS20xxB MM
Spectrum Analyzer Amplitude Accuracy
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-17. Spectrum Analyzer 50 MHz Amplitude Accuracy Setup Table
Test Power Level @ 50 MHz Required Sensor B Reading
0dBm dBm
–4 dBm dBm
–10 dBm dBm
–14 dBm dBm
–20 dBm dBm
–24 dBm dBm
–30 dBm dBm
–34 dBm dBm
–40 dBm dBm
–44 dBm dBm
–50 dBm dBm
Table A-18. Spectrum Analyzer 50 MHz Amplitude Accuracy
Test Power
Specification
(for SN <1441001)
Reference
Level Atten Level Measured Value Deviation
0dBm ±1.25dB (±1.3dB) 10dBm 30dB dBm dB
–4 dBm ±1.25 dB (±1.3 dB) 10 dBm 30 dB dBm dB
–10dBm ±1.25dB (±1.3dB) 0dBm 20dB dBm dB
–14dBm ±1.25dB (±1.3dB) 0dBm 20dB dBm dB
–20dBm ±1.25dB (±1.3dB) –10dBm 10dB dBm dB
–24dBm ±1.25dB (±1.3dB) –10dBm 10dB dBm dB
–30dBm ±1.25dB (±1.3dB) –20dBm 0dB dBm dB
–34dBm ±1.25dB (±1.3dB) –20dBm 0dB dBm dB
–40dBm ±1.25dB (±1.3dB) –30dBm 0dB dBm dB
–44dBm ±1.25dB (±1.3dB) –30dBm 0dB dBm dB
–50dBm ±1.25dB (±1.3dB) –40dBm 0dB dBm dB
