Model MS20xxB MM PN: 10580-00303 Rev. D 5-1

Chapter 5 — Battery Information

5-1 Introduction

This chapter describes battery information for VNA Master Models MS2024B, MS2025B, MS2034B, and

MS2035B.

Note

Some of the procedures in this section are generic, and apply to many similar instruments. Photos

and illustrations are representative and may show instruments other than the MS2024B, MS2025B,

MS2034B, and MS2035B.
