Test Records A-3 MS2025B Test Record
Model MS20xxB MM PN: 10580-00303 Rev. D A-3
A-3 MS2025B Test Record
VNA Frequency Accuracy
VNA Transmission Dynamic Range
_____ Refer to Attached Test Data Report
VNA Return Loss Measurements Accuracy
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-3. VNA Frequency Accuracy
VNA Output Frequency Specification Frequency Counter Reading
1 GHz ±2.5 kHz kHz
Table A-4. VNA Return Loss Measurement Accuracy
Return Loss Specification Measured Value
6dB 5.05dB ≤ x ≤ 6.95 dB dB
20 dB 18.39 dB ≤ x ≤ 21.61 dB dB
