Model MS20xxB MM PN: 10580-00303 Rev. D 6-1
Chapter 6 — Removal and Replacement
6-1 Introduction
This chapter describes the removal and replacement procedures for the various assemblies of VNA Master
Models MS2024B, MS2025B, MS2034B, and MS2035B. Illustrations (drawings or photographs) in this manual
may differ slightly from the instrument that you are servicing, but the basic removal and replacement
functions will remain as specified. The illustrations are meant to provide assistance with identifying parts and
their locations.
The Main/VNA PCB Assembly for MS202xB instruments, and the Main/VNA/DSP PCB Assembly for
MS203xB instruments may also be described as the Mother Board. In all four VNA Master Models, the VNA
circuitry is on the Mother Board: ND72051, ND72052, ND72117, and ND72118. The complete list of
replaceable parts is documented in Table 1-7 on page 1-8.
Figures of Instrument Construction
The figures at the beginning of this chapter reveal the inner construction of the VNA Master instruments.
• “Internal Anatomy of All Four VNA Master Models” on page 6-3
• “First Step for Opening the Case” on page 6-3
• “Screws on Case Back” on page 6-4
• “Basic Case Parts” on page 6-5
• “MS20xxB Instrument Overview” on page 6-6
• “Internal Anatomy of MS202xB” on page 6-7
• “MS202xB Separating Case Back from Case Front” on page 6-7
• “MS202xB Parts in Case Front” on page 6-8
• “MS202xB Connector Panel” on page 6-9
• “Internal Anatomy of MS203xB” on page 6-10
• “MS203xB Separating Case Back from Case Front” on page 6-10
• “MS203xB Parts in Case Front” on page 6-11
• “MS203xB Connector Panel” on page 6-12
• “PCB Assembly Out Of Case” on page 6-20
• “PCB Cable connections” on page 6-22
• “Ethernet PCB Assembly” on page 6-27
Note
Some of the procedures in this section are generic, and apply to many similar instruments. Photos
and illustrations are representative and may show instruments other than the MS2024B, MS2025B,
MS2034B, and MS2035B.
