Test Records A-4 MS2034B Test Record
Model MS20xxB MM PN: 10580-00303 Rev. D A-5
Spectrum Analyzer Displayed Average Noise Level (DANL)
Spectrum Analyzer Frequency Accuracy
Spectrum Analyzer Frequency Accuracy (Option 31, GPS)
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-9. Spectrum Analyzer DANL with Preamp Off
Start
Freq
Stop
Freq RBW VBW Specification
Measured Values at
100 kHz RBW
Calculated Values for
10 Hz RBW
10MHz2.4GHz100kHz 1kHz <
–131 dBm dBm dBm
2.4GHz 4.0GHz 100kHz 1kHz <
–127 dBm dBm dBm
Table A-10. Spectrum Analyzer DANL with Preamp On
Start
Freq
Stop
Freq RBW VBW Specification
Measured Values at
100 kHz RBW
Calculated Values for
10 Hz RBW
10 MHz 2.4 GHz 100 kHz 1 kHz ≤ –147 dBm dBm dBm
2.4GHz 4.0GHz 100kHz 1kHz ≤ –144 dBm dBm dBm
Table A-11. Spectrum Analyzer Frequency Accuracy
Frequency Specification Measured Value Deviation
1GHz ±1.5kHz (±1.5ppm)
a
a.To account for Aging, add 1 kHz (1 ppm) per year (after the first year) to the value stated in the Specification column.
GHz kHz
3.9GHz ±5.85kHz (±1.5ppm)
b
b.To account for Aging, add 3.9 kHz (1 ppm) per year (after the first year) to the value stated in the Specification column.
GHz kHz
Table A-12. Spectrum Analyzer Frequency Accuracy with GPS On
Frequency Specification Measured Value Deviation
3.9 GHz ±195 Hz (± 50 ppb) GHz Hz
