A-4 MS2034B Test Record Test Records
A-6 PN: 10580-00303 Rev. D Model MS20xxB MM
Spectrum Analyzer Single Side Band (SSB) Phase Noise
Spectrum Analyzer Spurious Response (Second Harmonic Distortion)
Spectrum Analyzer Input Related Spurious (IRS) Signals
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-13. Spectrum Analyzer SSB Phase Noise
Offset Frequency Specification Measured Value Calculated Value
10 kHz ≤ –100 dBc/Hz dBc/Hz dBc/Hz
100 kHz ≤ –105 dBc/Hz dBc/Hz dBc/Hz
1MHz ≤ –115 dBc/Hz dBc/Hz dBc/Hz
Table A-14. Spectrum Analyzer Spurious Response (Second Harmonic Distortion
Frequency Specification Measured Value 2nd Harmonic Level
50.1 MHz dBm
100.2 MHz ≤ –56 dBc dBm dBc
Table A-15. Spectrum Analyzer Input Related Spurious (IRS) Signals
Frequency Specification Measured Values Calculated IRS
2072.5 MHz dBm
1222.5 MHz to 2072 MHz ≤ –60 dBc dBm dBc
2073 MHz to 2922.5 MHz ≤ –60 dBc dBm dBc
1500 MHz dBm
1219 MHz to 1221 MHz ≤ –52 dBc dBm dBc
1689.5 MHz to
1691.5 MHz
≤ –52 dBc dBm dBc
2821 MHz to 2823 MHz ≤ –52 dBc dBm dBc
2421.5 MHz dBm
2505 MHz to 2507 MHz ≤ –39 dBc dBm dBc
To Next Page
