Anritsu VNA Master MS2024B - B-3 T3377 Test Fixture Schematic

B-3 T3377 Test Fixture Schematic Test Fixture Schematics
B-2 PN: 10580-00303 Rev. D Model MS20xxB MM
B-3 T3377 Test Fixture Schematic
Figure B-2. T3377 Test Fixture Schematic
130-200-3
200, 5%, 3.25 W
130-200-3
200, 5%, 3.25 W
101-10-5
10, 5%, 0.25 W
513-32
101-10-5
10, 5%, 0.25 W
