3-9 Amplitude Accuracy Spectrum Analyzer Performance Verification
3-24 PN: 10580-00303 Rev. D Model MS20xxB MM
Amplitude Accuracy Across Frequency Verification
Equipment Required
Synthesized Signal Generator, Anritsu Model MG3692X
K(m) to N(f) Adapter, Anritsu Model 34RKNF50
10 MHz Reference Standard
BNC(m) to BNC(m) Coaxial Cable, Anritsu part number 2000-1627-R
Dual Channel Power Meter, Anritsu Model ML2438A
High Accuracy Power Sensors (Quantity 2), Anritsu Model SC7400
RF Coaxial Cable, Anritsu Model 15NN50-1.5C
Power Splitter, Aeroflex/Weinschel Model 1870A
10 dB Fixed Attenuator, Aeroflex/Weinschel Model 44-10
N(m) to N(m) Adapter, Anritsu Model 34NN50A
Procedure
Test Setup Characterization
1. Turn on the 10 MHz Reference Standard, the ML2438A Power Meter, the MG3692X Signal Generator,
and the MS20XXB VNA Master.
2. Install the 34RKNF50 Adapter to the MG3692X Signal Generator output and then connect the
15NN50-1.5C Cable to the 34RKNF50 Adapter.
3. Connect the Power Splitter to the open end of the 15NN50-1.5C Cable.
4. Connect Sensor B to one of the Power Splitter outputs
Note Before continuing, allow a 30-minute warm up period for the internal circuitry to stabilize.
