Anritsu VNA Master MS2024B Maintenance Manual

Test Records A-4 MS2034B Test Record
Model MS20xxB MM PN: 10580-00303 Rev. D A-7
Spectrum Analyzer Resolution Bandwidth Accuracy
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-16. Spectrum Analyzer Resolution Bandwidth Accuracy
RBW Span VBW Lower Limit Measured Values Upper Limit
3 MHz 6 MHz 300 kHz 2.7 MHz MHz 3.3 MHz
1 MHz 2 MHz 100 kHz 0.9 MHz MHz 1.1 MHz
300 kHz 600 kHz 30 kHz 270 kHz kHz 330 kHz
100 kHz 200 kHz 10 kHz 90 kHz kHz 110 kHz
30 kHz 60 kHz 3 kHz 27 kHz kHz 33 kHz
10kHz 20kHz 1kHz 9kHz kHz 11kHz
3 kHz 6 kHz 300 Hz 2.7 kHz kHz 3.3 kHz
1 kHz 2 kHz 100 Hz 0.9 kHz kHz 1.1 kHz
300 Hz 600 Hz 30 Hz 270 Hz Hz 330 Hz
100 Hz 200 Hz 10 Hz 90 Hz Hz 110 Hz
30Hz 60Hz 3Hz 27Hz Hz 33Hz
10 Hz 20 Hz 3 Hz 9 Hz Hz 11 Hz
