6-4 Internal Anatomy of MS203xB Removal and Replacement
6-12 PN: 10580-00303 Rev. D Model MS20xxB MM
MS203xB Connector Panel
1. External Reference In
2. External Trigger In
3. RF In
4. USB Mini-B (Full Speed, USB 2.0)
5. GPS Antenna (with Option 31)
6. External Power
7. USB Type A (Full Speed, USB 2.0)
8. Headphone
9. Ethernet LAN Connector (with Option 411)
10.VNA Port 1 50 ohm (Green LED indicates the Port is Transmitting Power)
11. VNA Port 2 50 ohm (Green LED indicates the Port is Transmitting Power)
Figure 6-10. MS203xB Connector Panel
1
3
7
10
8
2
5
4
6
11
9
