Anritsu VNA Master MS2024B Maintenance Manual

1-8 Performance Verification Procedures General Information
1-10 PN: 10580-00303 Rev. D Model MS20xxB MM
1-8 Performance Verification Procedures
Performance verification procedures are in the following Chapters:
• Chapter 2, “VNA Performance Verification”
• Chapter 3, “Spectrum Analyzer Performance Verification”
• Chapter 4, “Options Performance Verification”
Refer to Table 1-8 for the list of performance verification procedures that are required for each model. Perform
all of the procedures that have an “X” in the Std column. Also perform the procedures with a “X” in the Opt 10
and Opt 31 columns when these options are installed in the VNA Master.
Table 1-8. Required Performance Verification Procedures for Each Model of VNA Master MS20xxB
Model Performance Verification Procedure Std
Opt
10
Opt
31
Procedure
in
MS2024B
VNA Frequency Accuracy X Chapter 2
VNA Transmission Dynamic Range X Chapter 2
VNA Return Loss Measurements Accuracy X Chapter 2
VNA Mode Bias Tee Operational Check X Chapter 4
GPS Operational Check X Chapter 4
MS2025B
VNA Frequency Accuracy X Chapter 2
VNA Transmission Dynamic Range X Chapter 2
VNA Return Loss Measurements Accuracy X Chapter 2
VNA Mode Bias Tee Operational Check X Chapter 4
GPS Operational Check X Chapter 4
MS2034B
VNA Frequency Accuracy X Chapter 2
VNA Transmission Dynamic Range X Chapter 2
VNA Return Loss Measurements Accuracy X Chapter 2
VNA Mode Bias Tee Operational Check X Chapter 4
GPS Operational Check X Chapter 4
Spectrum Analyzer Residual Spurious Response X Chapter 3
Spectrum Analyzer Displayed Average Noise Level (DANL) X Chapter 3
Spectrum Analyzer Frequency Accuracy X Chapter 3
Spectrum Analyzer Frequency Accuracy with GPS On X Chapter 4
Spectrum Analyzer Single Side Band (SSB) Phase Noise X Chapter 3
Spectrum Analyzer Spurious Response (Second Harmonic
Distortion)
X Chapter 3
Spectrum Analyzer Input Related Spurious (IRS) Signals X Chapter 3
Spectrum Analyzer Resolution Bandwidth (RBW) Accuracy X Chapter 3
Spectrum Analyzer Amplitude Accuracy X Chapter 3
Spectrum Analyzer Third Order Intercept (TOI) X Chapter 3
