Removal and Replacement 6-3 Internal Anatomy of MS202xB
Model MS20xxB MM PN: 10580-00303 Rev. D 6-7
6-3 Internal Anatomy of MS202xB
MS202xB Separating Case Back from Case Front
1. Battery Cable and Connection to Mother Board
Figure 6-5. Opening the Case
1
