A-5 MS2035B Test Record Test Records
A-18 PN: 10580-00303 Rev. D Model MS20xxB MM
Spectrum Analyzer Frequency Accuracy
Spectrum Analyzer Frequency Accuracy (Option 31, GPS)
Single Side Band (SSB) Phase Noise
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-36. Spectrum Analyzer Frequency Accuracy
Frequency Specification Measured Value Deviation
1 GHz ±1.5 kHz (±1.5 ppm)
a
a.To account for Aging, add 1 kHz (1 ppm) per year (after the first year) to the value stated in the Specification column.
GHz kHz
3.9 GHz ±5.85 kHz (±1.5 ppm)
b
b.To account for Aging, add 3.9 kHz (1 ppm) per year (after the first year) to the value stated in the Specification column.
GHz kHz
5.9 GHz ±8.85 kHz (±1.5 ppm)
c
c.To account for Aging, add 5.9 kHz (1 ppm) per year (after the first year) to the value stated in the Specification column.
GHz kHz
Table A-37. Spectrum Analyzer Frequency Accuracy with GPS On
Frequency Specification Measured Value Deviation
5.9 GHz ±295 Hz (±50 ppb) GHz Hz
Table A-38. Spectrum Analyzer SSB Phase Noise
Offset Frequency Specification Measured Value Calculated Value
10 kHz ≤ –100 dBc/Hz dBc/Hz dBc/Hz
100 kHz ≤ –105 dBc/Hz dBc/Hz dBc/Hz
1MHz ≤ –115 dBc/Hz dBc/Hz dBc/Hz
