6-2 Internal Anatomy of All Four VNA Master Models Removal and Replacement
6-6 PN: 10580-00303 Rev. D Model MS20xxB MM
MS20xxB Instrument Overview
1. Touch Screen and LCD Display
2. Fan Inlet Vent
3. Top Bumper
4. Ventilation Exhaust Vent
5. Rotary Knob
6. Keypad
7. Ventilation Exhaust Vent
8. Bottom Bumper
Figure 6-4. Front View of MS2024B
1
4
7
2
5
6
3
8
