A-4 MS2034B Test Record Test Records
A-4 PN: 10580-00303 Rev. D Model MS20xxB MM
A-4 MS2034B Test Record
VNA Frequency Accuracy
VNA Transmission Dynamic Range
_____ Refer to Attached Test Data Report
VNA Return Loss Measurements Accuracy
Spectrum Analyzer Residual Spurious Response
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-5. VNA Frequency Accuracy
VNA Output Frequency Specification Frequency Counter Reading
1GHz ±2.5kHz kHz
Table A-6. VNA Return Loss Measurement Accuracy
Return Loss Specification Measured Value
6dB 5.05dB ≤ x ≤ 6.95 dB dB
20 dB 18.39 dB ≤ x ≤ 21.61 dB dB
Table A-7. Spectrum Analyzer Residual Spurious Response with Preamp Off
Start Freq Stop Freq RBW VBW Specification Measured Values
10 MHz 50 MHz 1 kHz 300 Hz ≤ –90 dBm dBm
50 MHz 2.0 GHz 3 kHz 10 kHz ≤ –90 dBm dBm
2.0GHz 4.0GHz 1kHz 1kHz ≤ –90 dBm dBm
Table A-8. Spectrum Analyzer Residual Spurious Response with Preamp On
Start Freq Stop Freq RBW VBW Specification Measured Values
10 MHz 1.0 GHz 1 kHz 300 Hz ≤ –90 dBm dBm
1GHz 4.0GHz 3kHz 10kHz ≤ –90 dBm dBm
