4-4 Spectrum Analyzer Frequency Accuracy with GPS On Options Performance Verification
4-6 PN: 10580-00303 Rev. D Model MS20xxB MM
4-4 Spectrum Analyzer Frequency Accuracy with GPS On
The following test is used to verify the frequency accuracy of the spectrum analyzer with GPS On for MS2034B
and MS2035B.
Equipment Required
• GPS Antenna, Anritsu part number 2000-1528-R or Trimble part number 57861-00
• Synthesized Signal Generator, Anritsu Model MG3692X series
• K(m) to N(f) Adapter, Anritsu Model 34RKNF50
• 10 MHz Reference Standard
• RF Coaxial Cable, Anritsu Model 15NN50-1.5C
• BNC(m) to BNC(m) Coaxial Cable, Anritsu part number 2000-1627-R
Procedure
1. Connect GPS Antenna to the GPS Antenna connector of the MS203XB VNA Master.
2. Connect BNC Coaxial Cable between the 10 MHz Reference Standard output and the 10 MHz Ref In
connector of the Anritsu MG3692X Synthesized Signal Generator.
Note
Ensure that the Anritsu GPS Antenna is in a direct line-of-sight relationship to the GPS satellites or
the Antenna is placed outside without any obstructions.
Note Do not connect the external 10 MHz Reference to the VNA Master.
