Options Performance Verification 4-3 GPS (Option 31) Operational Check
Model MS20xxB MM PN: 10580-00303 Rev. D 4-5
18. Remove the adapter and terminator from the GPS connector of the VNA Master.
GPS Receiver Operational Check (For MS2024B and MS2025B Only)
19. Connect the GPS Antenna to the GPS connector of the VNA Master.
20. Press the GPS On/Off submenu button to turn on the GPS feature.
21. Verify that GPS indicator does turn green, which indicates the GPS receiver of the VNA Master can
acquire satellite signals.
22. Press the GPS On/Off submenu button to turn on the GPS feature.
Note
For MS2034B and MS2035B, go to Section Section 4-4 “Spectrum Analyzer Frequency Accuracy
with GPS On”.
Note
Ensure that the Anritsu GPS Antenna is in a direct line-of-sight relationship to the GPS satellites or
the Antenna is placed outside without any obstructions.
Note
Acquiring satellites may take as long as three minutes. The GPS indicator will turn green after at
least three satellites has been tracked by the GPS receiver.
