Model MS20xxB MM PN: 10580-00303 Rev. D 4-1
Chapter 4 — Options Performance
Verification
4-1 Introduction
This chapter contains tests that are used to verify the performance of options that are installed in VNA Master
Models MS2024B, MS2025B, MS2034B, and MS2035B. Blank performance verification test records are
provided in Appendix A. Make a copy of the blank test records and use them to record measured values.
The test procedures are as follows:
• “VNA Mode Bias Tee (Option 10) Operational Check” on page 4-2
• “GPS (Option 31) Operational Check” on page 4-4
• “Spectrum Analyzer Frequency Accuracy with GPS On” on page 4-6
Caution Verify that all equipment has warmed up for at least 30 minutes before making any measurements.
