6-3 Internal Anatomy of MS202xB Removal and Replacement
6-8 PN: 10580-00303 Rev. D Model MS20xxB MM
MS202xB Parts in Case Front
1. Keyboard Cable and Connector on Mother Board
2. Fan Cable and Connector Location
3. LCD Cable and Connector Location
Figure 6-6. Parts in Front Case
1
1
2
2
3
3
