1-2 Product Description General Information
1-2 PN: 10580-00303 Rev. D Model MS20xxB MM
1-2 Product Description
The MS202xB VNA Master is a portable handheld vector network analyzer featuring precise performance and
essential RF capabilities. It is designed to conduct accurate vector-corrected 1-port magnitude, phase, and fault
location measurements and 2-port magnitude, phase, group delay measurements from 500 kHz to 6 GHz.
The MS203xB VNA Master is a portable handheld instrument with integrated vector network analysis and
spectrum analysis capabilities in a single instrument. It offers the same vector network analysis capability as
the MS202xB VNA Master as well as spectrum analysis capability that provides quick and accurate
measurement results for monitoring, measuring, and analyzing signal environments. The spectrum analyzer
offers board spectrum analysis with frequency coverage to 6 GHz, impressive dynamic range, and excellent
phase noise performance. Standard measurements include field strength, occupied bandwidth (OBW), channel
power, adjacent channel power ratio (ACPR), and carrier to interference (C/I) ratio.
Frequency Ranges
Standard Accessories
Table 1-1. Frequency Ranges
Instrument Frequency Range
MS2024B VNA, 500 kHz to 4 GHz, N Connectors
MS2025B VNA, 500 kHz to 6 GHz, N Connectors
MS2034B VNA, 500 kHz to 4 GHz, N Connectors
SPA, 100 kHz to 4 GHz, N Connectors
MS2035B VNA, 500 kHz to 6 GHz, N Connectors
SPA, 100 kHz to 6 GHz, N Connectors
Table 1-2. Standard Accessories
Anritsu Part Number Accessory
10580-00301 MS20xxB User Guide
2300-498 Master Software Tools CD ROM
633-44 Rechargeable battery, Li-Ion
40-187-R AC – DC Adapter
806-141-R Automotive 12 Volt DC Adapter
3-2000-1498 USB A-mini B Cable, 3 meters (10 feet)
2000-1654-R Soft Carrying Case
