Anritsu VNA Master MS2024B Maintenance Manual

6-2 Internal Anatomy of All Four VNA Master Models Removal and Replacement
6-4 PN: 10580-00303 Rev. D Model MS20xxB MM
Screws on Case Back
Figure 6-2 shows the 6 screw locations for opening the case (arrows) and also shows the 4 screws that secure
the tilt bail.
Figure 6-2. Location of Six Screws that Secure Case Back to Case Front
