Ansul R-102 Installation And Maintenance Manual

SECTION 9 – APPENDIX
UL EX3470 ULC EX3470
2014-SEP-01 REV. 11 PAGE 9-3
R-102 Restaurant Fire Suppression Manual
SYSTEM SELECTION GUIDE (Continued)
Total Tank Type of Carbon Dioxide Nitrogen
Flow No.* Quantity System Type of Hardware Cartridge Required Cartridge Required
78-82 8 Multiple 1.5 Gal. Reg. Release 101-30 (423443) LT-30-R (423435)
3 Gal. Additional Tank
(2) 3 Gal. Reg. Actuator N/A (2) LT-A-101-30 (423491)
(2) Double 3 Gal. Tank Box
78-82 8 Multiple Remote Mechanical Release 101-10 (423439) – –
(Optional) 3 Gal. Reg. Actuator 101-30 (423443) LT-A-101-30 (423491)
1.5 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
83-88 8 Multiple 3 Gal. Reg. Release 101-30 (423443) LT-30-R (423435)
3 Gal. Additional Tank
(2) 3 Gal. Reg. Actuator N/A (2) LT-A-101-30 (423491)
(2) Double 3 Gal. Tank Box
83-88 8 Multiple Remote Mechanical Release 101-10 (423439) – –
(Optional) 3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
89-99 9 Multiple Remote Mech. Release 101-10 (423439) N/A
(3) 3 Gal. Reg. Actuator N/A (3) LT-A-101-30 (423491)
(3) Double 3 Gal. Tank Box
89-93 9 Multiple Remote Mechanical Release 101-10 (423439) – –
(Optional) 3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
1.5 Gal. Additional Tank
3 Gal. Reg. Actuator 101-20 (423441) LT-30-R (423435)
94-99 9 Multiple Remote Mechanical Release 101-10 (423439) – –
(Optional) 3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-20 (423441) LT-30-R (423435)
* Based on 5 flow numbers for a 1.5 gal. system and 11 flow numbers for a 3 gal. system.
** If tanks are manifolded, only a “double tank” nitrogen cartridge (Part No. 423493) can be used.
*** If tanks are manifolded, either an LT-A-101-30 nitrogen cartridge (Part No. 423491) or a double tank cartridge (Part No. 423493) can be used.

Ansul R-102 Specifications

General

Agent	Ansulex Low pH Liquid Fire Suppressant
Activation	Automatic or manual
Temperature Range	32 °F to 120 °F (0 °C to 49 °C)
System Type	Wet Chemical
Application	Commercial Kitchens
Nozzle Coverage	Varies based on hazard and configuration
Detection	Thermal or Manual
Approval	UL 300
Nozzle Types	Appliance specific nozzles
Capacity	Varies by cylinder size
Material	Stainless Steel
Standards	NFPA 17A
Cylinder Sizes	1.5 to 3 gallons
