A7 Plus – OPERATOR'S MANUAL
The instrument is supplied non-sterile.
Before use, disinfect the lamp grip. The fiber optic and the eye
protection can be sterilised in a steam autoclave up to 135°C.
• Put the fiber optic ( c ) in its housing until it clicks.
• Attach the curing light handpiece to the end of its power hose and
tighten the ring nut ( e ).
• Take the lamp out of its housing on the assistant’s board or dentist's
board.
instrument activation is highlighted by the relevant managing
icon appearing on the TOUCH DISPLAY.
• Turn the front of the lamp and/or fiber optics to the position most
suitable for curing (wand, gun or intermediate position).
• Use the MODE button to select the desired cycle as previously directed
(the selected cycle is always indicated by the illuminated LED).
the curing light has a permanent memory therefore the last
cycle used will always be present the next time it is used.
• Place the fiber optics in the position required for curing.
the fiber optics should be placed as close as possible to the
material to be cured without touching it.
• Press button START to start the cycle.
Operating mode: work 2 consecutive cycles, rest 60
seconds.
when a programmed cycle is activated, the LEDs (1, 2, 3, B,
R, L) indicate the time that elapses (in multiples of 5 seconds)
and turn off every 5 seconds of operation.
The curing light comes with a beep that BEEPS when the
cycle starts, BEEPS every 5 seconds of operation and lastly
BEEPS twice at the end of the work cycle.
• Allow light emission to stop by itself. However, it can be stopped at any
time by simply pressing the START button again.
• The curing light is equipped with a system that signals
malfunctions by illuminating the LEDS in different
combinations (see next paragraph).
• The curing light is equipped with a cut-out.
