7.7. OPENING/CLOSING THE WATER UNIT SIDE COVER
Opening the cover:
• Disengage water unit side cover ( a ) after having operate the special locking handle ( h ).
• Slide the cover to the left (see figure) and turn it to reach the complete opening.
Closing the cover:
• Close the water unit side cover holding it as shown in the figure.
• Lock the cover sliding it to the right until the mechanical limit position is reached.
