A7 Plus – OPERATOR'S MANUAL
Suction starts by taking the tube off the board.
To adjust suction power, use the slider ( a ) located on the suction tube
holder grip.
suction tube suction control can be started/stopped by pressing
the pedal (o) on water unit base.
when the tube is put back in place, suction stops approximately
2 seconds later. This is done to dry the suction tubes.
Removing the suction tubes.
Always wear goggles and gloves to prevent contact with
infected material when removing the suction tubes.
Remove the suction tubes from the conveyor fittings by turning and
pulling the tube fitting.
Detach the suction tubes from the holders by turning and pulling the tube
fitting.
Never directly grasp the suction tube.
Cleaning the suction tubes.
As the dental units may be equipped with different suction systems
(liquid or wet ring, air) carefully follow the instructions provided by the
suction system manufacturer when disinfecting the system regarding the
product to be used, times and directions for use.
For cleaning of the suction system, it is recommended to
use STER 3 PLUS (CEFLA s.c.) diluted in a 6% solution
(equivalent to 60 ml of product in 1 litre of water).
Sterilization.
• Suction tube holder terminals: steam autoclave up to 135° C following
the instructions for the use of the device.
• Suction tubes: soak to cold-sterilise.
With the tubes, never use procedures where temperature
exceeds 55° C.
Maintenance.
Periodically lubricate the O-rings of the suction tube holder terminals
(see Paragraph 9.4.) using S1-Protective Lubricant for O-Rings
(CEFLA s.c.).
Note about biocompatibility.
Only use suction tubes supplied with the dental unit and original spare
tubes.
The suction tubes must comply with Biocompatibility Standard ISO
10993.
ISOLITE suction tube.
For ISOLITE suction tube operation, please refer to the specific use
instructions given by the manufacturer.
