11. TECHNICAL DATA
Installation plan:
97042086
Water delivery flow rate:
10 l/min
Technical manual:
97071156
Water consumption:
2 l/min.
Dental unit spare parts catalogue:
97023117
Water hardness:
< 25 °f (14 °d)
Dental chair spare parts catalogue:
97023117
Drain connection:
ø40 mm.
Maximum dental unit weight:
90 Kg.
Drainage flow rate:
10 l/min.
Maximum dental chair weight:
115 Kg.
Drain duct inclination:
10 mm/m.
Maximum dental chair load
capacity:
190 Kg.
Suction connection:
ø40 mm.
Rated voltage:
230V~
Suction vacuum (minimum):
65 mbar.
Nominal frequency:
50/60 Hz.
Suction flow rate:
450 l/min.
Absorbed power:
1500W
Type-approval:
CE 0051
Air connection:
1/2 Gas.
Electrical work in compliance with:
IEC 60364-7-710
Air supply pressure:
6-8 bar.
Dental unit packaging dimensions:
1570 x 780 x 1325(h)
Air flow rate:
82 l/min.
Dental chair packaging dimensions:
1510 x 730 x 1000(h)
Water connection:
1/2 Gas.
Dental unit packaging weight:
145 Kg.
Water supply pressure:
3-5 bar.
Dental chair packaging weight:
150 Kg.
FUSES
Identification
Value
Protection
Position
Dental unit.
Fuse F2
Fuse F4
Fuse F5
Fuse F6
T 12.5 A
T 6.3 A
T 6.3 A
T 6.3 A
230 V~: Dental unit power supply line.
Secondary protection: Water unit.
Secondary protection: Dental unit.
Secondary protection: Operating light.
Connection box.
Connection box.
Connection box.
Connection box.
Dental chair.
Fuse F1
T 6.3 A
230 V~: Dental chair power supply line.
Connection box.
Quick-couplings.
Fuse
T 2 A
230 V~: Power outlet supply line.
Connection box.
MONITOR power supply.
Fuse
T 4 A
21 V~ : MULTIMEDIA power line.
Dental chair card area.
