A7 Plus – OPERATOR'S MANUAL
• Secure irrigation line hose on instrument cord with the special plastic
clips supplied with the sterile kit.
use type A for scaler cord, and type B for micromotor cord.
Operation.
To enable/disable peristaltic pump operation, extract micromotor and
touch the relevant icon button:
Peristaltic pump not active.
Peristaltic pump active with
quantity of delivered saline
solution equal to 5.
pump activation is confirmed by an audible BEEP and by the
appearance of the relevant box close to the value of delivered
saline solution.
peristaltic pump activation is also signalled by a warning icon
(see paragraph 5.1.) on the TOUCH DISPLAY showing also the
value of delivered saline solution.
Should it be necessary, touch icon buttons or to change the
quantity of saline solution delivered by the peristaltic pump.
value setting range: 1 to 5. The quantity of delivered solution
associated to the settable values is:
- value 1: approx.35 cc/min,
- value 2: approx.50 cc/min,
- value 3: approx.70 cc/min,
- value 4: approx.90 cc/min,
- value 5: approx.100 cc/min.
the quantity of saline solution delivered by the peristaltic pump
can also be edited when the instrument is active.
