Patient monitor User’s manual
7
Output impedance
Rated 50Ω
ECG analog signals output
Bandwidth （ -3dB
refer to 10Hz
）
Diagnosis mode: 0.05 Hz to 120 Hz
Monitor mode: 0.5 Hz to 40Hz
Surgery mode: 1 Hz to 25Hz
Signal range
-5V to +5V
Signal delay
25 ms（in diagnosis mode, filter off）
Sensitivity
1V/mV±5%
PACE rejection/
strengthener
Non
IBP analog signals output
Bandwidth （ -3dB
refer to 1Hz）
0 Hz to 12.5 Hz
Signal delay
55 ms（filter off）
Sensitivity
1V/100mmHg ±5%
Nurse call output
Drive mode
Relay
Electric
specification
Connect to the isolated power supply and ≤60W, ≤2A,
≤36VDC, ≤25VAC
Isolated voltage
1500 VAC
Signal type
N.C., N.O.
Alarm delay time
<3 s
Defibrillator synchronization signal output
Output impedance
50Ω±10%
Delay
≤35 ms（from R wave crest to pulse raise）
Amplitude
High level : 3.5 V to 5 V, the maximal output current
1mA.
Low level: < 0.5V, the maximal input current 5mA.
Pulse width
100ms±10%
Rise and drop time
< 1ms
Digital video output （ DVI-D connector ） (only for AnyView A8 and
AnyView A6 )
Video signal
Single Link TMDS
