11
VI (Voice inversion) --- not available for USA consumer version
In AM, SAH, SAL, USB, LSB, CW modes
AGCF --- AGC speed fast
AGCM --- AGC speed medium
AGCS --- AGC speed slow
In auto mode, LSQ is selected for all AM modes and NSQ is selected for all FM modes.
RF-G ---- Receiver’s manual gain control by the squelch knob.
21 NT Auto Notch
22 NR Noise reduction (in AM modes)
23 Key lock
24 PRI Priority receive
25 DUP Frequency offset
26 PAS In VFO search mode, pass frequencies stored.
In program search mode, pass frequencies are stored in the current search bank.
In memory read mode, current receive frequency are set to pass channel.
27 HLD Delay time set to “HOLD” in VFO search mode, program search mode, memory
scan mode.
28 FRE Free time set to other than “OFF” in VFO search mode, program search mode,
memory scan mode.
29 C PC remote control mode
30 SD card inserted in the slot and recognized
(Note: Attenuator function is always activated automatically and no attenuator indicator is displayed on
the LCD screen. The s-meter indicates reflecting attenuation level.)
FRONT PANEL KEYS
[F] The [F] (function) key is used to select secondary functions on the keypad. When
pressed, “F” in reverse contrast appears on the top left corner of the LCD. The first
function of the keys are printed on their surfaces; the secondary functions are printed
in black directly above the corresponding key. To cancel the “F”, press this key again.
