Installing the clutch cover
REMOVING THE CLUTCH CONTROL PIN
BUSHING
•
Before carrying out the removal of the
bushing, it is necessary to thread the
inside to allow the extractor to tighten
sufficiently.
•
Warm up the cover.
•
Using a generic extractor, it is then
possible to remove the bushing from
the cover.
INSTALLING THE CLUTCH CONTROL PIN
BUSHING
•
Before carrying out the installation of
the bushing, it is necessary to warm up
the cover.
•
Position the guide (1) to insert the
bushing (2) as indicated in the figure.
•
Insert the bushing so that the process-
ing notch (3) is aligned with the notch
on the guide (4).
Specific tooling
020926Y Tool for fitting the clutch control
bushing
RSV4 Factory a-PRC Engine
ENG - 303
